Description
Model NO.: Input Voltage:
GL-C-008WL DC 5-24V
IC Quantity: Total Output Current:
800 Max 10A Max
N.W.: G.W.:
54.8g 67.2g
Operating Temperature: Size:
-20to+45℃ 23.5x48x89mm
Supported Chips:
WS2811, SK6812, SM16703P, WS2812B,etc.
Smart Phone APP control
APP configuration steps
Open the phone settings and enter WiFi settings, find “WLED-AP” and
connect to it with the password
“wled1234”.
After successful connecion, it will
automatically jump to the WLED
page(or enter the website 4.3.2.1 in
the browser to enter the WLED page).
Click “WIFI SETTINGS”, set the WiFi
account and password, and then click
“Save & Connect” at the top of the
screen to save.
Click the “+” in the upper right corner of the
screen, and then click “DISCOVER LIGHTS…”.
When the button below displays “Found WLED!”,
it means that the WLED controller has been
found.
High compatibility
Compatible with many strip light types
WS2812B
WS2811
WS2815
GS8208
TM1814
SM16703P
WS2813
SK6812
Scene display
Suitable for various indoor lighting applications
